高维无线多用户通信网络频谱资源动态分配算法

doi:10.13229/j.cnki.jdxbgxb.20240563

Abstract

Abstract:

In high-dimensional wireless multi-user communication networks， there is a problem of unreasonable spectrum resource allocation， which leads to uneven network load and unstable communication quality. Traditional spectrum resource allocation methods can not respond to dynamic changes in user needs in real time， resulting in low utilization efficiency of spectrum resources. Therefore， a dynamic allocation algorithm for spectrum resources in high-dimensional wireless multi-user communication networks was proposed. By determining the dynamic allocation program of spectrum resources， while considering the goals of communication network load balancing and communication quality， a dynamic allocation objective function of spectrum resources was constructed， and its constraint conditions were explained. An improved genetic algorithm was introduced to solve the objective function and the optimal solution for dynamic allocation of spectrum resources was obtained. The experimental results show that the maximum spectrum resource utilization rate obtained by the proposed algorithm reaches 95%， and the spectrum resource allocation results are consistent with the actual results， fully confirming that the proposed algorithm has better spectrum resource allocation performance.

Key words: spectrum resources, user needs, network performance, high-dimensional wireless multi-user communication network, dynamic allocation

CLC Number:

TN929.5

Yun GAO,Jian-hui ZHOU,Yan-ping GUO. Dynamic allocation algorithm of spectrum resources in high⁃dimensional wireless multi⁃user communication networks[J].Journal of Jilin University(Engineering and Technology Edition), 2025, 55(6): 2138-2144.

Figures/Tables 6

Fig.1

Fig.2

Table 1

Spectrum resources table"

代码	频段	频段名称
$ζ 1$	300~3 000 Hz	特低频
$ζ 2$	3~30 kHz	甚低频
$ζ 3$	30~300 kHz	低频
$ζ 4$	300~3 000 kHz	中频
$ζ 5$	3~30 MHz	高频
$ζ 6$	30~300 MHz	甚高频
$ζ 7$	300~3 000 MHz	特高频
$ζ 8$	3~30 GHz	超高频
$ζ 9$	30~300 GHz	极高频
$ζ 10$	300~3 000 GHz	至高频

Table 1

Fig.3

Fig.4

Table 2

Schematic table of spectrum resource allocation results"

频谱资源	实际结果	本文算法	对比算法1	对比算法2
$ζ 1$	2，8	2，8	5	2，8
$ζ 2$	5	5	9	5，15
$ζ 3$	9，15	9，15	2，15	4
$ζ 4$	10，11	10，11	10	10，11
$ζ 5$	1，4	1，4	1，4	1，9
$ζ 6$	12	12	12	12，14
$ζ 7$	6	6	6，8	6
$ζ 8$	13	13	13	13
$ζ 9$	3，14	3，14	3，14	3
$ζ 10$	7	7	7，11	7

Table 2
