自动驾驶车辆基于风险场的盲区避障方法

doi:10.13229/j.cnki.jdxbgxb.20241264

摘要/Abstract

摘要：

针对驾驶盲区场景下存在驾驶安全隐患的问题，提出了基于碰撞风险场模型的车辆协同避障规划算法。考虑车-车通信持续性的影响，构建了通信持续性风险场模型，将构建的风险场纳入到路径动态规划算法中，设计了基于通信持续性影响因子的自适应避障安全代价函数。仿真实验结果表明：所提出的基于风险模型的避障规划算法能够准确反映驾驶盲区下的动态风险，提高无人驾驶车辆在极端情况下的安全性。

关键词: 避障规划, 自动驾驶, 车车通信, 风险评估, 动态规划

Abstract:

To address the safety hazards in driving blind spot scenarios， a collaborative obstacle avoidance planning algorithm for vehicles based on a collision risk field model was proposed. Considering the impact of vehicle-to-vehicle communication continuity， a communication continuity risk field model is constructed. This risk field was incorporated into the dynamic path planning algorithm， and an adaptive obstacle avoidance safety cost function based on the communication continuity impact factor was designed. Simulation results demonstrate that the proposed risk model-based obstacle avoidance planning algorithm can accurately reflect dynamic risks in driving blind spots， enhancing the safety of autonomous vehicles in extreme situations.

Key words: obstacle avoidance planning, autonomous driving, vehicle-to-vehicle communication, risk assessment, dynamic programming

中图分类号:

U491.6

佟宁,乔亚星,蒋峻同,王丽智. 自动驾驶车辆基于风险场的盲区避障方法[J]. 吉林大学学报(工学版), 2026, 56(7): 1894-1903.

Ning TONG,Ya-xing QIAO,Jun-tong JIANG,Li-zhi WANG. Obstacle avoidance method for autonomous vehicles based on risk field in blind spot scenarios[J]. Journal of Jilin University(Engineering and Technology Edition), 2026, 56(7): 1894-1903.

图/表 10

图1

图2

图3

表1

表2

风险场参数设置"

参数	数值	描述
$l m a x$ /m	30.451 1	风险场影响最大范围
$l m i n$ /m	5.330 6	以车辆为中心的风险场边界
$δ$ /m	32.970 7	跟车距离
$M 1$ /kg	1 500	产生风险场的重力
$S m a x$ /（m·s^-1）	55.56	车道最大限速
$a$ /m	33.451 1	椭圆的长半轴
$b$ /m	3.5	椭圆的短半轴

表2

图4

图5

图6

图7

图8

参考文献 21

[1]	Li H M, Dong X, Rasheed I, et al. A software-defined networking roadside unit cloud resource management framework for vehicle ad hoc networks[J]. Journal of Advanced Transportation, 2022, 2022: 1-13.
[2]	Lu J Y, Peng Z X, Shi R W, et al. A quantitative blind area risks assessment method for safe driving assistance[J]. Journal of Systems Architecture, 2024, 150: 1-15.
[3]	Wang L H, Zhang F Q, Cui Y H, et al. Stochastic velocity prediction for connected vehicles considering V2V communication interruption[J]. IEEE Transactions on Intelligent Transportation Systems, 2023, 24(11): 11654-11667.
[4]	Jo J H, Shim J N, Kim B, et al. AoA-based position and orientation estimation using lens MIMO in cooperative vehicle-to-vehicle systems[J]. IEEE Journal on Selected Areas in Communications, 2023, 41(12): 3719-3735.
[5]	陈吉清, 翁楚滨, 兰凤崇. 智能车辆换道潜在冲突分析与风险量化方法[J]. 汽车工程, 2021, 43(11): 1565-1576, 1586.
	Chen Ji-qing, Weng Chu-bin, Lan Feng-chong. Potential conflict analysis and risk quantification method of intelligent vehicle lane change[J]. Automotive Engineering, 2021, 43(11): 1565-1576, 1586.
[6]	赵睿, 李云, 胡宏宇, 等. 基于V2I通信的交叉口车辆碰撞预警方法[J]. 吉林大学学报: 工学版, 2023, 53(4): 1019-1029.
	Zhao Rui, Li Yun, Hu Hong-yu, et al. Vehicle collision warning method at intersection based on V2I communication[J]. Journal of Jilin University(Engineering and Technology Edition), 2023, 53(4): 1019-1029.
[7]	郑讯佳, 蒋骏皓, 黄荷叶, 等. 行车风险量化新方法及其防控策略仿真研究[J]. 机械工程学报, 2024, 60(10): 207-221.
	Zheng Xun-jia, Jiang Jun-hao, Huang He-ye, et al. Novel quantitative approach for assessing driving risks and simulation study of its prevention and control strategies[J]. Journal of Mechanical Engineering, 2024, 60(10): 207-221.
[8]	Lee M, Jo K, Sunwoo M. Collision risk assessment for possible collision vehicle in occluded area based on precise map[C]∥IEEE International Conference on Intelligent Transportation Systems, Yokohama, Japan, 2017: 1-6.
[9]	封硕, 吉现友, 程博, 等. 融合动态障碍物运动信息的路径规划算法[J]. 计算机工程与应用, 2022, 58(21): 279-285.
	Feng Shuo, Ji Xian-you, Cheng Bo, et al. Path planning algorithm based on dynamic obstacle movement information[J]. Computer Engineering and Applications, 2022, 58(21): 279-285.
[10]	任玥, 郑玲, 张巍, 等. 基于模型预测控制的智能车辆主动避撞控制研究[J]. 汽车工程, 2019, 41(4): 404-410.
	Ren Yue, Zheng Ling, Zhang Wei, et al. A study on active collision avoidance control of autonomous vehicles based on model predictive control[J]. Automotive Engineering, 2019, 41(4): 404-410.
[11]	Szczepanski R. Safe artificial potential field-novel local path planning algorithm maintaining safe distance from obstacles[J]. IEEE Robotics and Automation Letters, 2023, 8(8): 4823-4830.
[12]	韩小健, 赵伟强, 陈立军, 等. 基于区域采样随机树的客车局部路径规划算法[J]. 吉林大学学报: 工学版, 2019, 49(5): 1428-1440.
	Han Xiao-jian, Zhao Wei-qiang, Chen Li-jun, et al. Local path planning of bus based on RS-RRT algorithm[J]. Journal of Jilin University(Engineering and Technology Edition), 2019, 49(5): 1428-1440.
[13]	Zheng Xun-jia, Zhang Di, Gao Hong-bo, et al. A novel framework for road traffic risk assessment with HMM-based prediction model[J]. Sensors, 2018, 18(12): 4313-4327.
[14]	Liu Fang-ming, Chen Jian, Zhang Qi-xia, et al. Online MEC offloading for V2V networks[J]. IEEE Transactions on Mobile Computing, 2023, 22(10): 6097-6109.
[15]	Meng Zong-lin, Xia Xin, Xu Run-sheng, et al. HYDRO-3D: hybrid object detection and tracking for cooperative perception using 3D LiDAR[J]. IEEE Transactions on Intelligent Vehicles, 2023, 8(8): 4069-4080.
[16]	Ke X C, Ho K C. Localization by doppler derivatives and doppler-shifted frequencies[J].EEE Transactions on Signal Processing, 2024, 72: 2890-2904.
[17]	Fomeni F D. A lifted-space dynamic programming algorithm for the quadratic knapsack problem[J]. Discrete Applied Mathematics, 2023, 335: 52-68.
[18]	Zhang Lin, Wu Da-de, Zhao Ming-jing, et al. Uncertainty relation and the constrained quadratic programming[J]. Physica Scripta, 2024, 99(6): 1-35.
[19]	Reiter R, Nurkanovic A, Frey J, et al. Frenet-Cartesian model representations for automotive obstacle avoidance within nonlinear MPC[J]. European Journal of Control, 2023, 74: 1-8.
[20]	Yoon S, Kwon Y, Ryu J, et al. Reinforcement-learning-based trajectory learning in frenet frame for autonomous driving[J]. Applied Sciences-Basel, 2024, 14(16):1-14.
[21]	Zhang Yi-xiao, Hao Rui, Zhang Ting-ting, et al. A trajectory optimization-based intersection coordination framework for cooperative autonomous vehicles[J]. IEEE Transactions on Intelligent Transportation Systems, 2022, 23(9): 14674-14688.
