面向高速公路服务区自洽能源系统的RAMS评价方法

doi:10.13229/j.cnki.jdxbgxb.20231056

Abstract

Abstract:

The promotion of self-consistent energy systems in highway service areas is a crucial initiative for achieving a dual-carbon strategy. However， the assessment of the resilience and energy efficiency of self-consistent energy systems in service areas remains a pressing challenge. This paper proposes an approach for assessing self-consistent energy systems in highway service areas. We analyzed the structure and characteristics of self-consistent energy systems， considering key indicators such as reliability， availability， maintainability， and safety. Subsequently， we established an assessment model and designed assessment strategies. In addition， the weights of various indicators were determined using the entropy weight-TOPSIS method， while the weights of system attributes were determined using an enhanced AHP-VIKOR method. We established a novel multi-criteria comprehensive assessment framework. Through analysis of comparison， the validity and rationality of the method system are verified by computing a self-consistent energy system in a service area as an example.

Key words: engineering of communication and transportation system, self-consistent energy system, highway service area, multi-criteria assessment framework, evaluation of reliability， availability， maintainability，safety

CLC Number:

U491.8

Yan-bo LI,Jing-yuan WANG,Yuan-yuan Chen,Shao-feng CHENG,Hao-nan LYU,Jun-shuo CHEN. RAMS assessment approach of self-consistent energy system in highway service areas[J].Journal of Jilin University(Engineering and Technology Edition), 2025, 55(7): 2243-2250.

Figures/Tables 10

Fig.1

Fig.2

Fig.3

Table 1

Assessment scores of self-consistent energy system"

月份	H	$Δ P w, t$	$Δ P s, t$	$Δ P L, t$	MTBF	AV	R_WECR	R_SECR	R_RE	$ρ S, W$	MTTR	MCTR	$λ F D$	$λ F A$
1月	0.423	0.750	0.500	0.944	0.966	0.438	0.519	0.963	0.667	0.963	0.083	0.936	0.984	0.996
2月	0.577	0.825	0.607	0.833	0.959	0.632	0.556	0.944	0.667	0.963	0.276	0.762	0.985	0.995
3月	0.797	1	0.679	0.556	0.945	0.834	0.611	0.907	0.667	0.963	0.464	0.324	0.984	0.995
4月	0.685	0.850	0.786	0.500	0.944	0.803	0.685	0.815	0.833	0.982	0.536	0.224	0.983	0.992
5月	0.557	0.775	0.857	0.667	0.923	0.663	0.704	0.778	1	1	0.434	0.119	0.982	0.992
6月	0.400	0.675	1	0.944	0.939	0.514	0.741	0.722	1	1	0.596	0.257	0.983	0.992
7月	0.308	0.525	0.857	1	0.947	0.422	0.741	0.759	0.833	0.982	0.568	0.303	0.981	0.990
8月	0.452	0.500	0.821	0.944	0.936	0.406	0.722	0.796	1	1	0.694	0.248	0.981	0.992
9月	0.681	0.525	0.786	0.833	0.944	0.648	0.685	0.889	0.833	0.982	0.749	0.112	0.982	0.993
10月	0.865	0.700	0.571	0.556	0.936	0.782	0.648	0.963	0.833	0.982	0.611	0.245	0.985	0.995
11月	0.692	0.775	0.536	0.722	0.939	0.631	0.556	0.982	0.5	0.944	0.345	0.556	0.986	0.995
12月	0.451	0.800	0.500	1	0.051	0.512	0.500	1	0.5	0.944	0.121	0.908	0.986	0.996

Table 1

Table 2

Reliability comprehensive evaluation matrix"

	$Δ P w, t$	$Δ P s, t$	MTBF	$Δ P L, t$
$Δ P w, t$	1	1	3	1/5
$Δ P s, t$	1	1	3	1/5
MTBF	1/3	1/3	1	1/5
$Δ P L, t$	5	5	5	1

Table 2

Table 3

Maintainability comprehensive evaluation matrix"

	$λ F D$	$λ F A$	MTTR	MCTR
$λ F D$	1	3	5	5
$λ F A$	1/3	1	5	5
MTTR	1/5	1/5	1	1
MCTR	1/5	1/5	1	1

Table 3

Table 4

Safety comprehensive evaluation matrix"

	$Δ P L, t$	$Δ P s, t$	$Δ P w, t$	H
$Δ P L, t$	1	3	3	5
$Δ P s, t$	1/3	1	1	3
$Δ P w, t$	1/3	1	1	3
H	1/5	1/3	1/3	1

Table 4

Table 5

Availability comprehensive evaluation matrix"

	$Δ P s, w$	AV	$R W E C R$	$R S E C R$	$R R E$
$Δ P s, w$	1	7	5	5	3
AV	1/7	1	1/3	1/3	1/5
$R W E C R$	1/5	3	1	1	1/5
$R S E C R$	1/5	3	1	1	1/5
$R R E$	1/3	5	5	5	1

Table 5

Fig.4

Table 6

References 17

[1]	刘洋, 刘吉成. 基于大数据与粒子群的清洁能源协同优化调度方法[J]. 吉林大学学报:工学版, 2023,53(5): 1443-1448.
	Liu Yang, Liu Ji-cheng. Collaborative optimization scheduling method of clean energy based on big data and particle swarm optimization [J]. Journal of Jilin University(Engineering and Technology Edition), 2023, 53(5): 1443-1448.
[2]	Xiong Y Q, Cheng Q. Effects of new energy vehicle adoption on provincial energy efficiency in China: From the perspective of regional imbalances[J]. Energy, 2023, 281: No.128324.
[3]	任建强, 王璐阳, 吴家浩, 等. 基于情景构建与推演的新能源电力设备运行风险评估[J]. 清华大学学报:自然科学版, 2022, 62(10): 1571-1578.
	Ren Jian-qiang, Wang Lu-yang, Wu Jia-hao, et al. Operating risk assessments of new energy power equipment based on scenario construction and deduction[J]. Journal of Tsinghua University(Science and Technology), 2022, 62(10): 1571-1578.
[4]	马静, 黄韦博, 聂珍存, 等. 基于新能源快速调节的孤岛微网弹性恢复策略[J]. 电网技术, 2024, 48(3): 1103-1115.
	Ma Jing, Huang Wei-bo, Nie Zhen-cun, et al. Elastic recovery strategy of island micro-network based on rapid adjustment of new energy[J]. Power System Technology, 2024, 48(3): 1103-1115.
[5]	王振刚, 陈渊睿, 曾军. 面向完全分布式控制的微电网信息物理系统建模与可靠性评估[J]. 电网技术, 2019, 43(7): 2413-2421.
	Wang Zhen-gang, Chen Yuan-rui, Zeng Jun. Modeling and reliability assessment of completely distributed microgrid cyber physical system[J]. Power System Technology, 2019, 43(7): 2413-2421.
[6]	郭伟, 安佳坤, 贺春光, 等. 计及冰灾影响的电力系统韧性评估与提升方法[J]. 电力系统及其自动化学报, 2021, 33(8): 116-122.
	Guo Wei, An Jia-kun, He Chun-guang, et al. Resilience assessment and improvement method for power system considering the influences of ice disaster[J]. Proceedings of the CSU-EPSA, 2021, 33(8): 116-122.
[7]	李响, 牛赛. 双碳目标下源-网-荷多层评价体系研究[J]. 中国电机工程学报, 2021, 41(): 178-184.
	Li Xiang, Niu Sai. Study on multi-layer evaluation system of source-grid-load under carbon-neutral goal[J]. Proceeding of the CSEE, 2021, 41(Sup.1): 178-184.
[8]	Chang K, Yu C, Liu S, et al. Design and application of power grid security risk assessment and hierarchical control system in natural disasters[C]∥International Conference on Power System Technology(POWERCON), Shenyang, China, 2021: 2080-2086.
[9]	Stover O, Karve P, Mahadevan S. Reliability and risk metrics to assess operational adequacy and flexibility of power grids[J]. Reliability Engineering & System Safety, 2023, 231: No.109018.
[10]	Chen P. Effects of the entropy weight on TOPSIS[J]. Expert Systems with Applications, 2021, 168: No.114186.
[11]	Gupta C, Gupta V. Requirements risk estimation Using TOPSIS method[C]∥The 27th Asia-Pacific Software Engineering Conference(APSEC), Singapore, 2020: 505-506.
[12]	Mo L. New energy industry investment risk assessment method based on fuzzy AHP[J]. International Journal of Global Energy Issues, 2023, 45(4,5): 436-447.
[13]	Hashemi A, Dowlatshahi M B, Nezamabadi-pour H. VMFS: A VIKOR-based multi-target feature selection[J]. Expert Systems with Application, 2021, 182: No.115224.
[14]	Khan M J, Kumam P, Kumam W. Theoretical justifications for the empirically successful VIKOR approach to multi-criteria decision making[J]. Soft Computing, 2021, 25(12): 7761-7767.
[15]	史卓鹏, 黄韦博, 李勇, 等. 基于转动惯量存储与释放的风电场快速功率调控策略[J]. 华北电力大学学报:自然科学版, 2024, 51(4): 35-48.
	Shi Zhuo-peng, Huang Wei-bo, Li Yong, et al. Wind farm rapid active power control strategy based on moment of inertia storage and release[J]. Journal of North China Electric Power University(Natural Science Edition), 2024, 51(4): 35-48.
[16]	李艳波, 李林宜, 刘维宇, 等. 基于TSO-MSMA算法在光伏系统MPPT中的研究[J]. 太阳能学报, 2023, 44(8): 324-330.
	Li Yan-bo, Li Lin-yi, Liu Wei-yu,et al. Research on TSO-MSMA algorithm in MPPT of photovoltaic systems[J]. Acta Energiae Solaris Sinica, 2023, 44(8): 324-330.
[17]	马苗苗, 邵黎阳, 刘向杰. 分布式预测控制在微电网协调控制中的应用[J]. 吉林大学学报:工学版,2020, 50(6): 2258-2265.
	Ma Miao-miao, Shao Li-yang, Liu Xiang-jie. Application of distributed predictive control in coordinated control of microgrid[J]. Journal of Jilin University (Engineering and Technology Edition), 2020, 50(6): 2258-2265.

Related Articles 15

[1]	Xiao-feng JI,Ruo-fan DENG,Xin QIAO,Hao-tian GUAN. Nonlinear influence of built environment on temporal aggregation modes of shared bicycles [J]. Journal of Jilin University(Engineering and Technology Edition), 2025, 55(7): 2233-2242.
[2]	Sheng-yu YAN,Ming-jie CHENG,Hong-ce TIAN,Hong-yu WANG,Yong-heng ZHOU,Bo-hao MA. Scheduling algorithm for battery electric vehicle in closed scenic area [J]. Journal of Jilin University(Engineering and Technology Edition), 2025, 55(6): 1984-1993.
[3]	Yan-yan QIN,Teng-fei XIAO,Qin-zhong LUO,Bao-jie WANG. Car-following safety analysis and control strategy for foggy freeway [J]. Journal of Jilin University(Engineering and Technology Edition), 2025, 55(4): 1241-1249.
[4]	Yi-yong PAN,Xiang-yu XU. Model for predicting severity of accidents based on MobileViT network considering imbalanced data [J]. Journal of Jilin University(Engineering and Technology Edition), 2025, 55(3): 947-953.
[5]	Xi-zhen ZHOU,He GONG,Dun-dun LI,Yan-jie JI,Jie YAN. Nonlinear model for impact of built environment on curb parking spaces occupancy [J]. Journal of Jilin University(Engineering and Technology Edition), 2024, 54(9): 2520-2530.
[6]	Ya-qin QIN,Zheng-fu QIAN,Ji-ming XIE. Vehicle cooperative obstacle avoidance strategy driven by CLAM model and trajectory data [J]. Journal of Jilin University(Engineering and Technology Edition), 2024, 54(5): 1311-1322.
[7]	Hong-tao LI,Lin-hong WANG,Jun-da LI. Influence of lighting and speed limit on visual search ability at highway intersections [J]. Journal of Jilin University(Engineering and Technology Edition), 2023, 53(8): 2287-2297.
[8]	Wei-tiao WU,Kun ZENG,Wei ZHOU,Peng LI,Wen-zhou JIN. Deep learning method for bus passenger flow prediction based on multi-source data and surrogate-based optimization [J]. Journal of Jilin University(Engineering and Technology Edition), 2023, 53(7): 2001-2015.
[9]	Zhen-liang LIU,Cun-bao ZHAO,Yun-peng WU,Mi-na MA,Long-shuang MA. Life⁃cycle seismic resilience assessment of highway bridge networks using data⁃driven method [J]. Journal of Jilin University(Engineering and Technology Edition), 2023, 53(6): 1695-1701.
[10]	Hong-fei JIA,Ying-jun XU,Li-li YANG,Nan WANG. League member selection and benefit distribution of commercial vehicles multi⁃modal transportation [J]. Journal of Jilin University(Engineering and Technology Edition), 2023, 53(4): 1060-1069.
[11]	Chao SUN,Hao-wei YIN,Wen-yun TANG,Zhao-ming CHU. Sensor deployment strategy and expansion inference of mobile phone data for traffic demand estimation [J]. Journal of Jilin University(Engineering and Technology Edition), 2023, 53(4): 1070-1077.
[12]	Zhi-wei LIU,Zheng-yun SONG,Jian-rong LIU. Impact of shared autonomous vehicles on choice of subway station connection methods [J]. Journal of Jilin University(Engineering and Technology Edition), 2023, 53(12): 3424-3431.
[13]	Jin XU,Yan-peng WANG,Hai-yuan CHEN,Xiao-bo ZHANG,Cun-shu PAN. Longitudinal driving characteristics and operating speed prediction model of cars on hairpin curves of mountainous roads [J]. Journal of Jilin University(Engineering and Technology Edition), 2023, 53(12): 3432-3445.
[14]	Wen-jing WU,Kang-bei XIONG,Li-li YANG,Si-xu PU. Optimization of bus transfer preferential strategy in passenger corridor based on mental account theory [J]. Journal of Jilin University(Engineering and Technology Edition), 2023, 53(11): 3113-3121.
[15]	Xiu-feng CHEN,Yu-tong GUO,Yue-chen WU,Da-yi QU,Meng-yuan GAO. Multi-objective optimization of trafﬁc signal timings based on dandelion algorithm [J]. Journal of Jilin University(Engineering and Technology Edition), 2023, 53(11): 3122-3129.

Metrics

Viewed

Full text

Abstract

Cited

Shared

Discussed

Comments

Recommended 0

No Suggested Reading articles found!

方法	R	A	M	S
本文方法	0.565 47	0.417 93	0.395 04	0.375 48
AHP	0.807 84	0.775 65	0.525 92	0.652 53
TOPSIS法	0.637 01	0.530 91	0.487 693	0.487 69
熵权法	0.25	0.20	0.25	0.25
