混合交通流环境下车辆编队与碳排放特性

doi:10.13229/j.cnki.jdxbgxb.20240775

Abstract

Abstract:

To address the limitations of traditional models in accurately characterizing the dynamic evolution of vehicle platoons and interactions with heterogeneous behaviors of human-driven vehicles （HDV） in mixed traffic flows， this paper proposes a hybrid traffic flow modeling framework integrating discrete motion rules and dynamic platoon evolution. First， a discrete motion safety distance model is developed to resolve the distortion problem in continuous acceleration modeling by introducing integer decision rules based on cellular spacing. Second， a platoon size transition probability matrix is constructed using Markov chains to dynamically characterize the splitting， merging， and reorganization processes of platoons. Finally， multi-scenario simulation data are employed to quantify the impact mechanisms of intra-platoon spacing， reaction time， lane-changing behavior， and platoon size on CO? emissions. The results indicate that： When the CAV penetration rate exceeds 0.6， platoon mode can effectively improve the operational state of mixed traffic flow， and significantly reduces CO? emissions， with a reduction range of 18.2% to 25.1%； Optimizing intra-platoon spacing achieves a peak emission reduction of 42.5%； Lane-changing strategies must adapt to traffic density—enhancing HDV lane-changing probability under low density can achieve carbon emission reductions， while restricting CAV lane-changing probability to 0.4~0.6 under high density； Platoon sizes of 3~5 vehicles demonstrate optimal emission reduction efficiency. This paper reveals the mechanism of queue dynamic parameters on carbon emissions， and provides theoretical support for the optimization of intelligent connected fleet cooperative control strategies and the design of low-carbon transportation systems.

Key words: engineering of communication and transportation system, mixed traffic flow, vehicle platoon, discrete movement rules, dynamic evolution, carbon emissions

CLC Number:

U491

Wen-hui ZHANG,Mei-ru YE,Cong XI,Zi-wen SONG. Vehicle formation and carbon emission characteristics in mixed traffic flow environment[J].Journal of Jilin University(Engineering and Technology Edition), 2026, 56(2): 416-430.

Figures/Tables 16

Fig.1

Table 1

Parameter value in simulation"

参数	符号	数值
车身长度/m	$l n + 1$	5
最大速度/（m·s^-1）	$v m a x$	33
队内车间距/m	$d C A C C$	3
最大车队规模/辆	$Z$	6
期望加速度/（m·s^-2）	$a$	3
制动减速度/（m·s^-2）	$b$	5
HDV反应时间/s	$τ H D V$	1.4
CAV反应时间/s	$τ C A V$	0.5

Table 1

Fig.2

Fig.3

Fig.4

Fig.5

Fig.6

Table 2

Correlation coefficient Ki,je(K'i,je) of CO2 emission"

$K i, j e (K' i, j e)$		$j = 0$	$j = 1$	$j = 2$	$j = 3$
$a ≥ 0$	$i = 0$	6.916	0.217	2.345×10⁴	-3.639×10⁴
	$i = 1$	0.027 54	0.968×10²	-0.175×10²	8.35×10⁵
	$i = 2$	-2.070×10⁴	-1.013 8×10⁴	1.966×10⁵	-1.02×10⁶
	$i = 3$	9.80×10⁷	3.66×10⁷	-1.08×10⁷	8.50×10⁹
$a < 0$	$i = 0$	6.915	-0.032	-9.17×10³	-2.886×10⁴
	$i = 1$	0.028 4	8.53×10³	1.15×10³	-3.06×10⁶
	$i = 2$	-2.266×10⁴	-6.594×10⁵	-1.289×10⁵	-2.68×10⁷
	$i = 3$	1.11×10⁶	3.20×10⁷	7.56×10⁸	2.95×10⁹

Table 2

Fig.7

Table 3

Fig.8

Table 4

Table 5

Fig.9

Fig.10

Fig.11

References 16

[1]	邱小平, 于丹, 孙若晓, 等. 基于安全距离的元胞自动机交通流模型研究[J]. 交通运输系统工程与信息, 2015, 15(2): 54-60.
	Qiu Xiao-ping, Yu Dan, Sun Ruo-xiao, et al. Cellular automata model based on safety distance[J]. Journal of Transportation Systems Engineering and Information Technology, 2015, 15(2): 54-60.
[2]	常玉林, 张成祥, 张鹏. 车联网环境下基于间隙优化的无信号交叉口车速控制方法[J]. 重庆理工大学学报:自然科学, 2021, 35(3): 10-17.
	Chang Yu-lin, Zhang Cheng-xiang, Zhang Peng. A speed control method of non-signalized intersection based on gap optimization under connected vehicle environment[J]. Journal of Chongqing University of Technology (Natural Science), 2021, 35(3): 10-17.
[3]	王曦, 杨秀建, 贾晓寒, 等. 面向队列实际行为特性的混合交通流建模及分析[J]. 系统仿真学报, 2024, 36(4): 929-940.
	Wang Xi, Yang Xiu-jian, Jia Xiao-han, et al. Modeling and analysis of hybrid traffic flow considering actual behavior of platoon[J]. Journal of System Simulation, 2024, 36(4): 929-940.
[4]	Hu G, Lu W, Whalin R, et al. Analytical approximation for macroscopic fundamental diagram of urban corridor with mixed human and connected & autonomous traffic[J]. IET Intelligent Transport System, 2021, 15: 261-272.
[5]	Qin Y, Wang H. Analytical framework of string stability of connected and autonomous platoons with electronic throttle angle feedback[J]. Transportation A: Transport Science, 2018, 17(1): 59-80.
[6]	Sharma A, Zheng Z D, Kim J, et al. Assessing traffic disturbance, efficiency, and safety of the mixed traffic flow of connected vehicles and traditional vehicles by considering human factors[J]. Transportation Research Part C: Emerging Technologies, 2021, 124: No.102934.
[7]	杨志发, 孙勃, 樊贤俊, 等. 车路协同背景下高速公路货车车队的能耗仿真[J]. 吉林大学学报: 工学版, 2023, 53(12): 3452-3457.
	Yang Zhi-fa, Sun Bo, Fan Xian-jun, et al. Simulation on energy consumption of truck fleet on expressway under background of vehicle-infrastructure cooperative environment[J]. Journal of Jilin University (Engineering and Technology Edition), 2023, 53(12): 3452-3457.
[8]	Liang K Y, Mårtensson J, Johansson K H. Heavy-duty vehicle platoon formation for fuel efficiency[J]. IEEE Transactions on Intelligent Transportation Systems, 2016, 17(4): 1051-1061.
[9]	杨秀建, 李金雨. 基于非线性模型预测控制的车辆纵向队列协调控制[J]. 汽车工程, 2020, 42(2): 184-190.
	Yang Xiu-jian, Li Jin-yu. Coordinated control of vehicular platooning based on nonlinear model predictive control[J]. Automotive Engineering, 2020, 42(2): 184-190.
[10]	秦严严, 王昊, 冉斌. CACC车辆跟驰建模及混合交通流分析[J]. 交通运输系统工程与信息, 2018, 18(2): 60-65.
	Qin Yan-yan, Wang Hao, Ran Bin. Car-following modeling for CACC vehicles and mixed traffic flow analysis[J]. Journal of Transportation Systems Engineering and Information Technology, 2018, 18(2): 60-65.
[11]	Veldhuizen R, Raemdonck G V, Krieke V D. Fuel economy improvement by means of two European tractor semi-trailer combinations in a platooning formation[J]. Journal of Wind Engineering and Industrial Aerodynamics, 2019, 188: 217-234.
[12]	Zhai C J, Luo F, Liu Y G. Cooperative look-ahead control of vehicle platoon for maximizing fuel efficiency under system constraints[J]. IEEE Access, 2018, 99: 1-11.
[13]	徐明诚, 徐利伟, 殷国栋, 等. 燃油车和纯电车混杂智能网联队列系统的节能与稳定控制[J]. 汽车安全与节能学报, 2024, 15(1): 71-82.
	Xu Ming-cheng, Xu Li-wei, Yin Guo-dong, et al. Stability control and energy-saving of an intelligent networked platoon system composed of fuel vehicles and pure electric vehicles[J]. Journal of Automotive Safety and Energy, 2024, 15(1): 71-82.
[14]	蒋阳升, 王思琛, 高宽, 等. 混入智能网联车队的混合交通流元胞自动机模型[J]. 仿真学报, 2022, 34(5): 1025-1032.
	Jiang Yang-sheng, Wang Si-chen, Gao Kuan, et al. Cellular automata model of mixed traffic flow composed of intelligent connected vehicles' platoon[J]. Journal of System Simulation, 2022, 34(5): 1025-1032.
[15]	魏丽英, 吴润泽. 基于鱼群效应的智能网联车队形成与演化机理研究[J]. 交通运输系统工程与信息, 2024, 24(2): 76-85.
	Wei Li-ying, Wu Run-ze. Formation and evolution mechanism of connected and autonomous fleet based on fish streaming effect[J]. Journal of Transportation Systems Engineering and Information Technology, 2024, 24(2): 76-85.
[16]	惠飞, 吴丽宁, 景首才, 等. 基于轨迹数据的多工况典型驾驶行为能耗评估[J]. 计算机应用与软件, 2020, 37(5): 50-56.
	Hui Fei, Wu Li-ning, Jing Shou-cai, et al. Energy consumption assessment of typical driving behavior under multiple driving conditions based on trajectory date[J]. Computer Applications and Software, 2020, 37(5): 50-56.

Related Articles 15

[1]	Yu-sheng CI,Yi-kang HUANG. Overview of intersection vehicle-infrastructure integration based on bibliometrics [J]. Journal of Jilin University(Engineering and Technology Edition), 2026, 56(2): 313-332.
[2]	Zhao-wei QU,Ming-yang WANG,Zhe WANG,Xian-min SONG,Yun-xiang ZHANG,Jing-cheng HUANG. Adaptive scheduling method for bus based on autonomous modular vehicles main⁃auxiliary function allocation [J]. Journal of Jilin University(Engineering and Technology Edition), 2025, 55(9): 2946-2957.
[3]	Shu-you YU,Ze-peng LIU,Bao-jun LIN,Hong CHEN. Data⁃driven distributed predictive control of vehicle platoons [J]. Journal of Jilin University(Engineering and Technology Edition), 2025, 55(9): 3056-3068.
[4]	Chang-ru MU,Liang XU,Guo-zhu CHENG. Collision prevention performance of outsourced U-shaped steel concrete composite guardrail based on reasonable energy allocation [J]. Journal of Jilin University(Engineering and Technology Edition), 2025, 55(8): 2669-2680.
[5]	Yan-bo LI,Jing-yuan WANG,Yuan-yuan Chen,Shao-feng CHENG,Hao-nan LYU,Jun-shuo CHEN. RAMS assessment approach of self-consistent energy system in highway service areas [J]. Journal of Jilin University(Engineering and Technology Edition), 2025, 55(7): 2243-2250.
[6]	Xiao-feng JI,Ruo-fan DENG,Xin QIAO,Hao-tian GUAN. Nonlinear influence of built environment on temporal aggregation modes of shared bicycles [J]. Journal of Jilin University(Engineering and Technology Edition), 2025, 55(7): 2233-2242.
[7]	Shu-you YU,Hua-cheng XIE,Wen-bo LI,Yong-fu LI,Hong CHEN,Bao-jun LIN. Digital twin driven longitudinal and lateral control of truck platoon [J]. Journal of Jilin University(Engineering and Technology Edition), 2025, 55(6): 1994-2002.
[8]	Sheng-yu YAN,Ming-jie CHENG,Hong-ce TIAN,Hong-yu WANG,Yong-heng ZHOU,Bo-hao MA. Scheduling algorithm for battery electric vehicle in closed scenic area [J]. Journal of Jilin University(Engineering and Technology Edition), 2025, 55(6): 1984-1993.
[9]	Yan-yan QIN,Teng-fei XIAO,Qin-zhong LUO,Bao-jie WANG. Car-following safety analysis and control strategy for foggy freeway [J]. Journal of Jilin University(Engineering and Technology Edition), 2025, 55(4): 1241-1249.
[10]	Wen-hui ZHANG,Bo FU,Ge ZHOU,Xiao-tian QIAO. Carbon emissions calculation for urban buses throughout lifecycles [J]. Journal of Jilin University(Engineering and Technology Edition), 2025, 55(4): 1232-1240.
[11]	Yi-yong PAN,Xiang-yu XU. Model for predicting severity of accidents based on MobileViT network considering imbalanced data [J]. Journal of Jilin University(Engineering and Technology Edition), 2025, 55(3): 947-953.
[12]	Yong-zheng YANG,Zhi-gang DU,Jia-lin MEI. Setting method and effect evaluation of linear guiding system in highway tunnels [J]. Journal of Jilin University(Engineering and Technology Edition), 2025, 55(12): 3885-3897.
[13]	Guang-yong CHEN,Shi-rui ZHOU,Chu-qing TAO,Li WAN,Wei WEI. Collaborative control of tunnel speed and lighting based on driver’s visual characteristics [J]. Journal of Jilin University(Engineering and Technology Edition), 2025, 55(12): 3898-3906.
[14]	Qing-chang LU,Yong-quan REN,Jing LI,Xu MENG,Peng-cheng XU. Cascading failures of mixed traffic flows in road networks considering critical density [J]. Journal of Jilin University(Engineering and Technology Edition), 2025, 55(10): 3200-3207.
[15]	Xi-zhen ZHOU,He GONG,Dun-dun LI,Yan-jie JI,Jie YAN. Nonlinear model for impact of built environment on curb parking spaces occupancy [J]. Journal of Jilin University(Engineering and Technology Edition), 2024, 54(9): 2520-2530.

Metrics

Viewed

Full text

Abstract

Cited

Shared

Discussed

Comments

Recommended 0

No Suggested Reading articles found!

CAV 渗透率	CO₂排放总量/（L·km^-1）		下降比例/%
CAV 渗透率	离散模式	编队模式	下降比例/%
0.2	0.360 2	0.329 8	8.4
0.4	0.324 5	0.285 6	12.0
0.6	0.267 6	0.218 8	18.2
0.8	0.190 3	0.142 5	25.1

密度/ （辆·km^-1）	CO₂排放降低百分比/%
密度/ （辆·km^-1）	0.1	0.2	0.3	0.4	0.5	0.6
10	0.02	0.03	0.07	0.07	0.23	0.43
20	0.05	0.15	0.48	0.34	0.67	0.81
30	-1.40	-3.66	-2.54	-1.53	-2.82	-4.94
40	-0.20	0.10	-0.58	-0.41	-0.70	-1.83
50	0.02	0.37	0.50	0.42	0.32	-0.43
60	0.05	-0.01	0.10	-0.20	-0.15	-0.32
70	-0.03	-0.55	-0.80	-0.46	-1.18	-0.80
80	-0.06	-0.15	-0.38	-0.17	-0.58	-0.27

密度/ （辆·km^-1）	CO₂排放降低百分比/%
密度/ （辆·km^-1）	0.1	0.2	0.3	0.4	0.5	0.6
10	0.02	0.07	-0.07	0.01	0.01	0.03
20	-4.24	-1.34	-2.36	-3.07	-11.82	-1.76
30	-4.15	-5.30	-4.99	-5.07	-7.66	-4.54
40	-5.67	-2.79	-1.81	-4.79	-4.90	-2.25
50	-2.29	-1.57	-2.50	-3.15	-3.95	-3.46
60	-2.38	-1.98	-2.35	-2.71	-2.33	-2.32
70	0.05	-0.15	0.09	0.28	0.51	0.76
80	0.62	0.06	0.84	1.34	1.67	1.45
