基于改进非洲秃鹫算法的TDOA-AOA定位

doi:10.13229/j.cnki.jdxbgxb.20230076

摘要/Abstract

摘要：

针对到达时间差定位（Time difference of arrival，TDOA）和到达角定位（Angle of arrival，AOA）联合定位，提出了基于准反射学习机制和并行机制改进的非洲秃鹫定位算法。改进的非洲秃鹫算法在对定位模型最大似然的适应度函数寻优和迭代过程中，引入准反射机制以丰富种群多样性和加快收敛速度，在一定程度上也平衡了探索和开发能力；引入并行机制，通过一个种群的最优个体指导另一种群，加快收敛速度，增强了寻优性能。实验结果看，将改进的非洲秃鹫算法与非洲秃鹫算法（AVOA）、改进的哈里斯鹰算法（IHHO）、混沌麻雀搜索优化算法（CSSOA）、鸽群优化算法（PIO）、疯狂自适应樽海鞘算法（CASSA）进行对比，在基准函数和定位模型的求解上，都表现出了更快的收敛速度、更准确的定位精度和更好的稳定性。

关键词: 信息处理技术, 到达时间差定位, 到达角定位, 非洲秃鹫算法, 准反射学习

Abstract:

For joint localization of time difference of arrival （TDOA） and angle of arrival （AOA）， an improved African vulture localization algorithm based on quasi reflective learning mechanism and parallel mechanism was proposed. The improved African vulture introduced a quasi reflection mechanism to enrich population diversity and speed up convergence in the process of searching for the maximum likelihood fitness function of the location model and in the iterative process， which also balanced the exploration and exploitation capabilities to a certain extent； The parallel mechanism was introduced to guide another population through the optimal individual of one population， which speeds up the convergence speed and enhances the optimization performance. From the results， the improved African Vulture algorithm is compared with AVOA， IHHO， CSSOA， PIO and CASSA， and shows faster convergence speed， more accurate positioning accuracy and better stability in solving the benchmark function and positioning model.

Key words: information processing technology, time difference of arrival, angle of arrival, african vultures optimization algorithm, quasi reflection

中图分类号:

TP277

肖剑,刘经纬,胡欣,齐小刚. 基于改进非洲秃鹫算法的TDOA-AOA定位[J]. 吉林大学学报(工学版), 2024, 54(12): 3558-3567.

Jian XIAO,Jing-wei LIU,Xin HU,Xiao-gang QI. TDOA⁃AOA location based on improved african vulture algorithm[J]. Journal of Jilin University(Engineering and Technology Edition), 2024, 54(12): 3558-3567.

图/表 10

图1

图2

表1

基准函数"

Functions	$D$	$R a n g e$
$F 1 = ∑ i = 1 n x i 2$	$100$	$[- 100,100] D$
$F 2 = ∑ i = 1 n x i - ∏ i = 1 n x i$	$100$	$[- 10,10] D$
$F 3 = ∑ i = 1 n (∑ j = 1 i x j) 2$	$30$	$[- 100,100] D$
$F 4 = m a x i {x i, 1 ≤ i ≤ n}$	$30$	$[- 100,100] D$
$F 5 = - 20 e (- 0.2 1 n ∑ i = 1 n x i 2) ???????? - e (1 n ∑ i = 1 n c o s (2 π x i) + 20 + e$	$10$	$[- 32,32] D$
$F 6 = 0.1 {s i n 2 (3 π x i) ????????? + ∑ i = 1 n - 1 (x i - 1) [1 + s i n 2 (3 π x i + 1)] ????????? + (x n - 1) [1 + s i n 2 (2 π x n)]} ?????????? + ∑ i = 1 n u (x i, 5,100,4)$	$100$	$[- 50,50] D$

表1

图3

表2

基准函数仿真结果"

函数	值	PQRAVOA	AVOA	IHHO	CSSOA	PIO	CASSA
$F 1$	Ave	0	7.763E-120	0	2.556E-228	6.673E-12	2.624E-13
$F 1$	Std	0	1.731E-119	0	0	1.481E-11	4.465E-13
$F 2$	Ave	2.074E-217	2.641E-60	4.058E-187	8.177E-106	1.479E-8	8.448E-6
$F 2$	Std	0	5.813E-60	0	1.698E-105	2.196E-8	1.842E-5
$F 3$	Ave	0	2.218E-76	1.937E-284	1.039E-165	2.045E-12	9.342E-9
$F 3$	Std	0	4.202E-76	0	0	2.132E-12	2.089E-8
$F 4$	Ave	1.915E-212	3.967E-60	1.953E-162	1.309E-111	6.588E-7	5.463E-10
$F 4$	Std	0	8.385E-60	4.445E-162	1.511E-111	1.369E-7	5.712E-10
$F 5$	Ave	3.801E-9	1.522E-3	8.922E-3	7.711E-5	7.202	13.606
$F 5$	Std	3.778E-9	1.191E-3	1.429E-2	8.332E-5	8.228	10.969
$F 6$	Ave	1.113E-11	4.541E-8	4.718E-5	7.469E-9	9.601E-3	2.232E-2
$F 6$	Std	1.003E-11	2.134E-8	4.652E-5	1.671E-8	1.285E-2	3.323E-2

表2

图4

图5

图6

图7

表3

不同距离噪声下的均方根误差对比"

$σ (m)$	RMSE
$σ (m)$	AVOA	PQRAVOA	CSSOA	IHHO	CASSA	PIO
0.1	0.040 5	0.011 9	0.016 3	0.066 2	0.235 3	0.029 3
0.2	0.058 7	0.022 6	0.025 8	0.079 2	0.241 9	0.042 8
0.3	0.073 1	0.035 1	0.036 9	0.085 8	0.247 2	0.061 6
0.4	0.083 6	0.046 7	0.049 2	0.093 9	0.248 3	0.075 5
0.5	0.092 2	0.055 1	0.061 2	0.108 7	0.284 8	0.092 9
0.6	0.100 4	0.064 2	0.073 2	0.113 4	0.299 3	0.103 4
0.7	0.111 1	0.076 5	0.080 6	0.123 1	0.275 4	0.114 1
0.8	0.119 1	0.088 8	0.097 2	0.138 5	0.305 9	0.127 1
0.9	0.124 2	0.099 2	0.103 5	0.147 6	0.301 1	0.131 7
1.0	0.131 9	0.108 5	0.117 8	0.158 2	0.288 1	0.148 9

表3

参考文献 24

1	Wang G, Zhu W, Ansari N. Robust TDOA-based localization for IoT via joint source position and NLOS error estimation[J]. IEEE Internet of Things Journal, 2019, 6(5): 8529-8541.
2	Wang Y, Ho K C. An asymptotically efficient estimator in closed-form for 3-D AOA localization using a sensor network[J]. IEEE Transactions on Wireless Communications, 2015, 14(12): 6524-6535.
3	Wang Y, Ho K C. Unified near-field and far-field localization for AOA and hybrid AOA-TDOA positionings[J]. IEEE Transactions on Wireless Communications, 2017, 17(2): 1242-1254.
4	岳俊升, 程钢, 邓超. 标签高度差的UWB室内定位方法[J]. 导航定位学报, 2019, 7(3): 44-50.
	Yue Jun-sheng, Cheng Gang, Deng Chao. UWB indoor positioning method considering difference ofheight[J]. Journal of Navigation and Positioning,2019, 7(3): 44-50.
5	孔维炯, 丁志中, 方福柱. 基于TDOA的高精度无线定位算法分析与实现[J]. 合肥工业大学学报: 自然科学版, 2019, 42(6): 756-762.
	Kong Wei-jiong, Ding Zhi-zhong, Fang Fu-zhu. Analisys and realization of high precision radio positioning algorithm based on TDOA[J]. Journal of Hefei University of Technology (Natural Science), 2019,42(6): 756-762.
6	Wang G, Cai S, Li Y M, et al. A bias reduced nonlinear WLS method for TDOA /FDOA based source localization[J]. IEEE Transactions on Vehicular Technology, 2016,65 (10): 8603-8615.
7	赵拥军, 赵勇胜, 赵闯. 基于正则化约束总体最小二乘的单站DOA-TDOA 无源定位算法[J]. 电子与信息学报, 2016, 38(9): 2336-2343.
	Zhao Yong-jun, Zhao Yong-sheng, Zhao Chuang. Single-observer passive DOA-TDOA location based on regularized constrained total least squares[J]. Journal of Electronics & Information Technology,2016,38 (9): 2336-2343.
8	马一鸣, 石志东, 赵康.基于改进哈里斯鹰优化算法的TDOA 定位[J].计算机工程, 2020, 46(12): 179-184.
	Ma Yi-ming, Shi Zhi-dong, Zhao Kang. TDOA localization based on improved Harris hawk optimization algorithm[J]. Computer Engineering,2020,46(12):179-184.
9	国强, 朱国会, 李万臣. 基于混沌麻雀搜索算法的TDOA/FDOA定位[J]. 吉林大学学报: 工学版,2023, 53(2): 593-600.
	Guo Qiang, Zhu Guo-hui, Li Wan-chen. TDOA/FDOA localization based on chaotic sparrow search algorithm[J]. Journal of Jilin University (Engineering and Technology Edition), 2023, 53(2): 593-600.
10	陈涛, 王梦馨, 黄湘松. 基于樽海鞘群算法的无源时差定位[J]. 电子与信息学报, 2018, 40(7): 1591-1597.
	Chen Tao, Wang Meng-xin, Huang Xiang-song. Time difference of arrival passive location based on salp swarm algorithm[J]. Journal of Electronics & Information Technology, 2018, 40(7): 1591-1597.
11	苟平章, 孙梦源, 刘学治,等. 基于天牛须搜索优化的TDOA三维节点定位算法[J].传感器与微系统,2022, 41(10): 141-144.
	Gou Ping-zhang, Sun Meng-yuan, Liu Xue-zhi, et al. 3D node location algorithm based on optimization of BAS [J]. Transducer and Microsystem Technologies,2022, 41(10): 141-144.
12	Mirjalili S, Lewis A. The whale optimization algorithm[J]. Advances in Engineering Software,2016,95: 51-67.
13	Sm A, Smm B, Al A. Grey wolf optimizer[J]. Advances in Engineering Software, 2014, 69: 46-61.
14	Abbasi A, Firouzi B, Sendur P. On the application of Harris hawks optimization (HHO) algorithm to the design of microchannel heat sinks[J]. Engineering with Computers, 2021, 37(2): 1409-1428.
15	Nadimi-Shahraki M H, Taghian S, Mirjalili S,et al. EWOA-OPF: effective whale optimization algorithm to solve optimal power flow problem[J]. Electronics, 2021, 10(23): No.10232975.
16	Nadimi-Shahraki M H, Taghian S, Mirjalili S. An improved grey wolf optimizer for solving engineering problems[J]. Expert Systems with Applications, 2021, 166: No. 113917.
17	Fan Q, Chen Z, Xia Z. A novel quasi-reflected Harris hawks optimization algorithm for global optimization problems[J]. Soft Computing, 2020,24(19): 14825-14843.
18	王静静, 瞿少成, 李科林. 一种基于并行交叉遗传算法的二维不规则排样问题求解[J]. 计算机应用与软件, 2020, 37(7): 188-193.
	Wang Jing-jing, Zhai Shao-cheng, Li Ke-lin. A two-dimensional irregular layout problem solving based on parallel cross genetic algorithm[J]. Computer Applications and Software, 2020, 37(7): 188-193.
19	Abdollahzadeh B, Gharehchopogh F S, Mirjalili S. African vultures optimization algorithm: a new nature-inspired metaheuristic algorithm for global optimization problems[J]. Computers & Industrial Engineering, 2021, 158: No.107408.
20	Tizhoosh H R. Opposition-based learning: a new scheme for machine intelligence[C]∥International Conference on International Conference on Computational Intelligence for Modelling, Control & Automation, Vienna, Austria, 2005: 695-701.
21	Rahnamayan S, Tizhoosh H R, Salama M. Quasi-oppositional differential evolution[C]∥2007 IEEE Congress on Evolutionary Computation, Piscataway,USA, 2007: 2229-2236.
22	Ewees A A, Elaziz M A, Houssein E H. Improved grasshopper optimization algorithm using opposition-based learning[J]. Expert Systems with Applications,2018,112(Dec.): 156-172.
23	Pan J S, Tian A Q, Chu S C,et al. TDOA location based on pigeon-inspired optimization algorithm in WSNs[C]∥International Conference on Genetic and Evolutionary Computing.Berlin: Springer, 2021: 724-733.
24	张达敏, 陈忠云, 辛梓芸. 基于疯狂自适应的樽海鞘群算法[J]. 控制与决策, 2020, 35(9): 2112-2120.
	Zhang Da-min, Chen Zhong-yun, Xin Zi-yun. Algorithm based on crazy self-adaptive salvia group[J]. Control and Decision, 2020, 35(9): 2112-2120.
